OnePlus Ace 7 leaked schematic shows dual-airflow built-in cooling fan

Tipster Digital Chat Station shared a schematic of the OnePlus Ace 7's active cooling system with a built-in fan and dual-airflow architecture. The phone is expected to run on Snapdragon 8 Elite Gen 5 with a 6.78-inch 1.5K 185Hz OLED, a 9,000mAh battery and 100–120W charging.

• Fan pushes hot air sideways away from hands, cool air downward
• 6.78-inch OLED display with 1.5K resolution and 185Hz refresh rate
• Snapdragon 8 Elite Gen 5 with up to 16GB RAM and 1TB storage
• 9,000mAh battery with 100W or 120W charging
