CT scan reveals how the iPhone Duo hinge works

YouTuber HTX Studio CT-scanned the iPhone Duo hinge, revealing nearly 100 components across six sections, including synchronized gears and spring-and-cam pairs. The phone holds between 15 and 145 degrees, and the screen's bending radius is 3.85mm.

• Hinge packs nearly 100 components across six sections
• Screen holds at angles from 15 to 145 degrees
• Bending radius is 3.85mm versus 3.8–4.2mm on rivals
• Hinge assembly is wrapped in a titanium cover, rated IP68
